Vszerda DC12V 4.8A Cooling Fan PFC1212DE High Speed PWM Brushless Fan Temperature Control Cooler Fan Repair Parts

With USB:/

is_customized:/

Model Number:EATAD836

Air volume:252.85CFM (7.16m3/min)

Bearings:high-precision ball bearings

Blade:injection molding, PBT+30% glass fiber +V0 grade flame retardant

Current:4.8A

Fan frame:Injection molding, PBT+30% glass fiber +V0 grade flame retardant

Fan rotation:counterclockwise from the fan blade side

Insulation resistance:more than 500Meg ohm

Interface:motherboard 4P

Item:Cooling Fan

Line length:35cm

Model:PFC1212DE

Noise:66.5 dB (A)

Operating temperature:-10 degrees to +70 degrees Celsius

Power:57.6W

Power range:plus or minus of the rated power 15%

Revolution:12V under 5500RPM

Speed measurement:support

Speed regulation:support motherboard PWM speed regulation

Storage Temperature:-40 degrees to +70 Degrees Celsius

Voltage:DC12V

Wind pressure:1.412 in H2O (351.7 Pa)

Withstanding voltage:Meeting the leakage current 0.5mA 500V/1min

Working life:80000 hours at the ambient temperature 25 degrees

DC12V 4.8A Cooling Fan PFC1212DE High Speed PWM Brushless Fan Temperature Control Cooler Fan Repair Parts

Description:

l

for long time use

l

Replace the old, broken or non-working cooling fan

Learn more about the Detailed Specifications
